End Suction Pump
DC/DS-Horizontal End Suction Pump
LEADING Horizontal End Suction Pump SUPPLIERS IN CHINA
ViRheos is a leading professional manufacturer, supplier, and exporter of horizontal centrifugal pumps, boasting extensive industry experience. We specialize in the research, development, production, and sales of a diverse range of such centrifugal pumps. Our products are distinguished by exceptional stability, superior efficiency, and extended service life, having been successfully exported to global markets and earned widespread acclaim and high recognition from customers worldwide.
ABOUT DC/DS-HORIZONTAL END SUCTION PUMP
The DC and DS series horizontal end suction pumps are single-stage horizontal centrifugal pumps with robust, precision-engineered construction, featuring a pull-out design for easy maintenance, used in HVAC systems for air circulation and water supply boosting to ensure reliable pressure and flow, contributing to modern infrastructure’s quiet efficiency.. Key specs include:
- Temperature Range: -15°C to +70°C (normal) or +105°C (hot water)
- Motor: IEC cage-type, IP55 protection, F insulation, 3-phase 220-415V
- Operating Conditions: Clean, non-flammable liquids, ambient ≤40°C, altitude ≤1000m
- Performance: Curves based on ISO 9906, test at 20°C clean water, 2900/1480 rpm.
They’re ideal for heating, cooling, and water systems requiring reliable, low-maintenance operation.
If you need to obtain the detailed performance parameters and drawings, please download the horizontal END SUCTION PUMP PDF
horizontal End Suction Pump for sale
Looking for horizontal end suction centrifugal pump pricing? We offer competitive factory prices for bulk orders of these pumps. Detailed specifications, performance data, and quotation sheets are available in our suction pump PDF catalog. Please contact us immediately to discuss customized solutions and obtain instant quotes.
| Pump Type | Price Range (USD) | Application Scenarios |
| General End Suction Pump | ||
| Basic Model | 899 – 7,890 | Irrigation, water supply, drainage, and other conventional scenarios |
| Standard Industrial Model | 260 – 1,000 | Industrial fluid transfer, cooling systems, etc. |
| High-Power Model | 260 – 1,000 | High-flow, high-head demand scenarios |
| Specialized End Suction Pump | ||
| Marine/Drainage Pipe Pump | 3,000 – 7,000 | Marine, drainage pipes, and other special environments |
| Fire Pump (Mine Diesel-Driven) | 3,000 – 9,000 | Fire protection, mining, and other high-demand scenarios |
| Chemical Pump (Corrosion-Resistant Fluid Transfer) | 100 – 2,000 | Chemical, pharmaceutical, and other corrosion-resistant fluid transfer scenarios |
horizontal END SUCTION PUMP application
These pumps are widely applied in water supply scenarios, including water plant filtration, zonal distribution, pipeline pressurization, and high-rise building water supply. They also support industrial pressurization for process water, cleaning systems, and fire protection, as well as liquid transfer in cooling systems, boiler feedwater, and machine tool cooling. Additionally, they handle the transfer of oils, acids, and coolants, facilitate water treatment processes like reverse osmosis, and enable irrigation via sprinkler and drip systems.
| Application | Specific Use Cases |
| Water Supply | Water plant filtration and distribution, zonal water supply, main pipeline pressurization, high-rise building water supply, hotel pressurization, industrial water supply pressurization |
| Industrial Pressurization | Process water systems, cleaning systems, high-pressure cleaning systems, fire protection systems, vehicle washing equipment |
| Industrial Liquid Transfer & Cooling | Cooling and air conditioning systems, boiler feedwater, condenser systems and cooling towers, machine tool cooling and lubrication packages |
| Liquid Transfer | Oils and alcohols, acids and alkalis, ethylene glycol and coolants |
| Water Treatment | Ultrafiltration systems, reverse osmosis systems, distillation systems, separators, swimming pools |
| Irrigation | Regional irrigation, sprinkler irrigation, drip irrigation, greenhouse irrigation |
horizontal End Suction Pump Installation Diagram
As a professional Chinese water pump manufacturer, ViRheos takes pride in offering comprehensive technical support for our products. We provide our clients with detailed PDF documentation that covers complete technical parameters, standard installation diagrams, operational guidelines and maintenance tips specifically for our horizontal end suction pumps, helping users with accurate selection, smooth installation and reliable operation.
horizontal End Suction Pump parts
| Component Name | Function Description |
| Pump casing | The pump casing houses the fluid and guides its flow while bearing pressure. |
| Impeller | The impeller rotates to generate centrifugal force, propelling the fluid. |
| Pump cover | The pump cover seals the top of the casing to prevent fluid leakage. |
| Bracket | The bracket supports the pump shaft and stabilizes the pump structure. |
| Electric motor | The electric motor provides power to rotate the pump shaft. |
| Pump shaft | The pump shaft connects the motor to the impeller, transmitting power. |
| Mechanical Seal | The mechanical seal prevents fluid leakage from the gap between the shaft and casing. |
| O-ring | The O-ring seals the connection between the pump cover and casing. |
| Coupling | The coupling connects the motor shaft to the pump shaft, transmitting torque. |
| Base | The base supports the entire pump body, ensuring stable operation. |
horizontal END SUCTION PUMP factory
As a leading Chinese centrifugal water pump manufacturer, ViRheos is a professional supplier and exporter with rich industry expertise. Our factory produces durable stainless steel centrifugal pumps, plant pumps, commercial pumps and horizontal models, featuring exceptional stability, high efficiency and long service life. Engineered for diverse industrial and agricultural scenarios, they excel in water supply, pressurization, liquid transfer, water treatment and irrigation. Exported globally, our products enjoy wide customer acclaim. We offer detailed technical documents, competitive bulk pricing and customized solutions. Contact us for full specs and instant quotes.
VIRHEOS
Related posts
Common Problems and Solutions for horizontal End Suction Pump
What is a suction pump, and what are its main applications?
A suction pump draws and transfers liquids/slurries via suction force, used in agriculture, water/wastewater treatment, and construction. It includes water suction pumps, suction pumps for sewage, and drainage suction pumps for specific needs.
What is the difference between an end suction centrifugal pump and a double suction centrifugal pump?
End suction centrifugal pumps have one impeller inlet, compact for medium flow/head. Double suction ones have two inlets, reducing axial thrust for higher flow, suitable for large-scale water supply and industrial use.
When should I choose a horizontal end suction pump over other types?
Choose a horizontal end suction pump for horizontal space and easy maintenance. It fits HVAC, industrial lines, and water circulation, also available as a base mounted end suction pump for stable installation.
What is a close coupled end suction pump, and what are its advantages?
A close coupled end suction pump mounts the impeller directly on the motor shaft, saving space and reducing alignment issues. It’s cost-effective, efficient, ideal for small-medium water transfer/circulation.
Can a suction pump for sewage be used interchangeably with a regular water suction pump?
No. A suction pump for sewage handles solids/sludge with a large non-clog impeller. A regular water suction pump is for clean water, easily clogging or failing with sewage.
What are the key features of an end suction fire pump?
End suction fire pumps meet fire standards, with high reliability and quick startup. Base-mounted, fire-resistant, paired with electric/diesel drives, used in sprinkler and hydrant systems.
How does an electric water suction pump work, and what are its power requirements?
Electric water suction pumps use motors to drive impellers, drawing water via low pressure. Power needs vary: 0.5-2 HP for domestic, tens of HP for industrial, using single/three-phase power.
What is the purpose of a base mounted end suction pump, and when is it necessary?
Base mounted end suction pumps reduce vibration and ensure alignment. Necessary for high-power continuous use (industrial processes), simplifying installation and maintenance.
What factors should be considered when selecting a double suction pump?
Consider flow rate, total head, fluid properties, space, and maintenance. Also check efficiency, material compatibility, and application (water treatment, power plants) for double suction pumps.
Are suction pumps suitable for both clean water and drainage applications, and how to choose the right one?
Yes. Choose water suction/horizontal end suction centrifugal pumps for clean water, drainage suction pumps for dewatering, and suction pumps for sewage for solids-laden fluids.
