CAST IRON DEEP WELL SUBMERSIBLE PUMP
CAST IRON DEEP WELL SUBMERSIBLE PUMP
LEADING deep well submersible pump SUPPLIERS IN CHINA
ViRheos is a professional deep well pump manufacturer，supplier & exporter with rich industry experience, specializing in the R&D, production and sales of various end suction pumps. Our products feature stable performance, high efficiency and long service life, and are widely exported to global markets, winning high recognition from customers
ABOUT Cast Iron Deep Well Submersible Pump
This cast iron deep well submersible pump adopts a direct-coupled structural design, where the motor is directly connected to the pump body via a sleeve shaft. A water inlet filter is installed between the pump and the motor to effectively isolate impurities in the liquid. The entire unit is submerged in the liquid being conveyed, which helps prevent cavitation (a problem caused by the height difference between the pump and the liquid surface) from occurring in the pump.
The pump relies on the centrifugal force generated by the impeller driven by the motor to transport fluid from underground to the ground surface.
Its application system mainly consists of two parts: above-ground components and underground components:
- Above-ground components: Include control cabinets, cables, transformers, etc.
- Underground components: Include pipelines, pumps, and other accessories.
The above-ground components are connected to the underground components through delivery pipelines extending to the bottom of the well. Typically, the motor part of the submersible pump is installed below the hydraulic section.
If you need to obtain the detailed performance parameters and drawings, please download the deep well water pump PDF
CAST IRON DEEP WELL SUBMERSIBLE PUMP for sale
Looking for deep well submersible pump price ? We offer competitive factory price for deep well pump bulk orders, with detailed specs, performance data and quotation sheets available in our deep well water pump PDF—contact us now for customized solutions and instant quotes.
| Series | Price Range (USD) | Primary Use Case & Notes |
| Small-scale / Household & Agricultural Irrigation | 280–840 | Suitable for personal water supply, small farm irrigation, or villa water systems. Price varies based on exact depth, flow requirements, and material (e.g., cast iron vs. stainless steel components). |
| Medium-scale / Commercial & Community Water Supply | 840–2,800+ | Used for community wells, small commercial buildings, hotels, or larger irrigation projects. Higher power and multi-stage pumps for increased head and flow lead to a broader price range. |
| Large-scale / Industrial & Municipal Water Supply | Several thousand to tens of thousands USD | Designed for industrial processes, municipal water networks, mining dewatering, or large-area irrigation. Prices are highly customized based on engineering specs, materials (often full stainless steel), and system integration requirements. |
CAST IRON DEEP WELL SUBMERSIBLE PUMP application
QJ deep well submersible pump is suitable for Groundwater Extraction from wells. The pump can be used for Water Treatment Applications in rivers, reservoirs, canals, specifically for River/Reservoir Water Supply. It also can be used for Irrigation Systems and water supply for people and stocks in Mountain/Plateau Water Supply scenarios as well as Urban/Mine Drainage in cities, factories, railways, mines and construction sites.
| Applicable scenarios | Specific Applications |
| Groundwater extraction | Extracting groundwater from a well |
| Water Treatment Applications | Water supply from rivers, reservoirs, and channels |
| Irrigation system | Agricultural irrigation water supply |
| Highland/Mountainous Area Water Supply | Provide domestic water for residents and livestock |
| Urban/Mine Drainage | Drainage from cities, factories, railways, mines, and construction sites |
CAST IRON DEEP WELL SUBMERSIBLE PUMP Installation Diagram
As a professional Chinese submersible well pump manufacturer, ViRheos provides detailed technical parameters and deep well water pump installation diagrams in our deep well pump PDF.
CAST IRON DEEP WELL SUBMERSIBLE PUMP parts
| Part Category | Part Name | Main Function |
| Pump casing | Pump body, pump cover | To accommodate and protect internal components, and to withstand water pressure and mechanical stress. |
| Impeller | Motor, stator, rotor, motor shaft | Generate a rotating magnetic field, output mechanical energy, and transmit torque through the shaft. |
| Pump cover | Impeller, Guide Vane, Blade Shaft | Rotation exerts centrifugal force on water to increase pressure, collects high-speed water flow, and converts its kinetic energy into pressure energy. |
| Bracket | Drive shaft, coupling | Connect the motor to the pump shaft to transmit power. |
| Electric motor | Rubber bearings, seal rings, guide bearings | Support the rotating shaft, reduce friction, and prevent high-pressure water inside the pump from leaking along the shaft. |
| Pump shaft | Suction pipe, pump base, bracket | To convey water from underground wells to the surface, the pump body is fixed and designed to withstand weight and vibration. |
CAST IRON DEEP WELL SUBMERSIBLE PUMP factory
As a leading deep well water pump manufacturer in China, the deep well submersible pump factory excels in crafting durable stainless steel centrifugal pumps, plant pumps，commercial pump，specifically designed for efficient operations in diverse industrial and agricultural environments.
VIRHEOS
Related posts
Common Problems and Solutions for CAST IRON DEEP WELL SUBMERSIBLE PUMP
What is the difference between a deep well pump and a borehole pump?
A deep well pump is a general term for pumps used in deep water wells, while a borehole pump is specifically designed for narrow, drilled boreholes. Most borehole pumps are submersible, matching the slim structure of boreholes.
Which size of submersible pump should I choose for my well, like 2 inch submersible pump or 4 inch submersible pump?
Choose the pump size based on your well casing diameter. A 2 inch submersible pump fits slim casings, while a 4 inch submersible pump is ideal for standard wells and delivers higher flow rates.
What horsepower (hp) well pump do I need for a 300 ft deep well pump application?
For 300 ft deep wells, a 1 hp submersible well pump works for low water demand, while 1.5 hp or 2 hp well pump models are better for high-flow needs like irrigation or household use.
Can I use a solar water pump for deep well operations?
Yes, solar water pumps for deep wells are designed to operate off-grid, using solar panels to power the submersible motor. They are energy-efficient and suitable for remote areas.
How do I select the best deep well submersible pump?
Consider your well depth, water flow requirements, power supply (e.g., 220v for submersible deep well water pump 220v), and pump material durability for long-term use.
What is the advantage of a deep well hand pump 300 feet over electric pumps?
Deep well hand pumps 300 feet require no electricity, making them reliable backups during power outages, and they are low-maintenance for remote locations.
Where can I find deep well pumps for sale and submersible well pumps for sale?
You can find these pumps at industrial equipment suppliers, online pump retailers, and local hardware stores that specialize in water system products.
Is an industrial submersible pump suitable for residential deep well use?
Industrial submersible pumps are built for heavy-duty applications with high flow rates. They can be used for residential use if the flow and pressure requirements match, but they are usually more costly.
What factors affect the deep well water pump price?
Deep well water pump price is affected by horsepower, pump size, material quality, brand, and additional features like solar compatibility or stainless steel construction.
Do I need professional help for installing a deep well pump?
Yes, installing a deep well pump requires knowledge of well structure, electrical wiring (for electric models), and pump positioning. Professional installation ensures safety and optimal performance.
